A pacemaker is a small battery-powered electronic device that sends electrical signals to the heart to help it beat at a proper rate. It is surgically placed under the skin and connected to the heart by one or more wires or leads.

Pacemakers are used for cardiac conditions like bradycardia that disrupt the heart’s normal electrical system. Bradycardia is characterized by a slow or irregular heart rhythm. At a low rate, the heart is unable to pump enough oxygen-rich blood to the body during normal activity or exercise causing dizziness, fatigue, shortness of breath or fainting spells. Pacemakers are the most common way to treat bradycardia — restoring the heart’s normal rhythm and relieving symptoms by sending electrical impulses to the heart to increase the heart rate.

Pacemakers do not take over the work of the heart but assist in regulating the timing and sequence of the heartbeat. Pacemakers only work when they are needed. These devices are sophisticated enough to decide when support to the heart is required.

Over the years, the size of pacemakers has drastically changed. As technology advanced, the devices continued to shrink. Today’s pacemakers are about 2 inches wide and 1.5 inches high. In 2017, McLeod began offering a new device, the Micra a leadless pacemaker, that is 93 percent smaller than modern-day pacemakers. Micra weighs about the same as a penny and is the size of a vitamin capsule.

A leadless pacemaker means there are no leads to connect it to the heart. The technology consists of computer chips and a small battery in a sealed case that resembles a AAA battery. Micra delivers electrical impulses that pace the heart through an electrode located at the end of the device.

Currently, the Micra device is only available for patients with certain medical conditions and a slow heart rate that would require pacing in the lower chamber of the heart.

The original Micra does not cover all the medical problems that require the services of a pacemaker. This system previously did not provide the ability to synchronize the upper and lower chambers of the heart. A new treatment option in dual chamber pacing is the Micra AV.  Micra AV is for patients with AV block, a condition in which the electrical signals between the chambers of the heart are impaired.

Micra AV has internal sensing to detect activity of the upper chamber of the heart and deliver electrical pulses in the lower chamber maintaining time-based synchronization of the upper and lower chambers.

Micra AV is the same size as the original Micra. Both are so small they are delivered via a catheter, similar to the way a heart catheterization is performed. The catheter is inserted through a vein in the leg, guided by X-ray imaging and implanted directly into the heart muscle. Small tines (hooks) secure the device in place. Once in place inside the heart, there is no lump under the skin that can be felt as with a traditional pacemaker.

With the addition of Micra AV, the benefits of a leadless pacemaker can be extended to even more patients.  A cardiologist or electrophysiologist can help determine if a patient may be a candidate for a leadless pacemaker.
